Product Overview
The SWLLIFT bi-leveling tracked scissor lift is highly functional and of great value. It combines the advantages of tracked scissor lift and bi-leveling scissor lift. It can perform well even in environments where traditional aerial work platforms are difficult to operate safely. This equipment integrates a sturdy tracked chassis and advanced automatic leveling technology, enabling operators to work efficiently on uneven ground, slopes, gravel, mud, and other complex terrains. The self-leveling system can maintain stability, thereby enhancing the safety and efficiency of high-risk outdoor operations. The bi-leveling tracked scissor lift can automatically compensate for terrain changes, ensuring the platform remains level even when operating on slopes.
Appropriate terrain
This equipment performs particularly well in the following areas:
- Construction site
- Mountainous area
- Infrastructure construction
- Forestry operation
Its driving capabilities on soft ground, gravel roads, muddy surfaces and rough terrains make it an ideal choice for outdoor contractors.
Other styles of scissor lifts
Swllift is a well-established manufacturer of aerial work platforms. The scissor lifts are our best-selling products. Besides this type of scissor lift, we can also provide you with electric scissor lifts, diesel scissor lifts, off-road scissor lifts, tracked scissor lifts, and so on. Each type of scissor lift is suitable for different scenarios. If you don't know which type you should buy, you can tell our professionals about the scenarios you will use. They have extremely rich experience and can recommend the most suitable scissor lift for you based on your purpose.
Our factory employs advanced production equipment and strict quality control procedures to ensure consistent product performance. SWLLIFT has an unwavering commitment to quality.
Don't worry about the price or the quality. If you need to purchase a scissor lift right now, please contact us.
SWLLIFT will ensure that you purchase the scissor lift that suits you.
Parameter Information
| Model | SWGTJZ 1618 |
| Max. Working Height | 17.8m |
| Max. Platform Height | 15.8m |
| Max. Lift capacity | 300kg |
| Lift capacity--extension deck extended | 100kg |
| Working Platform Dimensions(L×W) | 2.63×1.13m |
| Overall dimensions of the machine unfolded guardrail(L×W×H) | 3×1.14×2.88m |
| Overall dimensions of the machine folding guardrails(L×W×H) | 3×1.14×2.26m |
| Slide-out platform extension deck-length | 0.9m |
| Minimum ground clearance | 106mm/29mm |
| Wheelbase | 2400m |
| Turning radius - inside/outside | 0/3.16m |
| Lift/drive motor | 24V-4.5KW |
| Lifting speed | 3-3m/min |
| Drive speed-stowed | 3.5km/h |
| Drive speed-raised | 0.8km/h |
| Battery | 4×12V/185Ah |
| Charger | 24V/30A |
| Max.climbing ability | 25% |
| Max. Working Angel | 2°/3° |
| Tires | 381*127 |
| Total Weight | 4300kg |
Construction Cases
