Product Overview：
Diesel small telescopic boom lift is characterized by safety, reliability, intelligence and high efficiency, smooth boom expansion and contraction, superior cross-country climbing and driving performance, and industry-leading platform dual-load capacity (300kg/454kg). It is suitable for the construction of large venues, municipal bridges, heavy industry plant facilities construction and maintenance and other construction environments.
Aerial working platform is a movable mechanical equipment used for operation at a certain height, lifting the operator, tools, materials, etc. to a certain position for construction, installation, maintenance, etc. through the platform, and providing safety protection for the operator. diesel small telescopic boom lift It can replace the traditional operation methods such as basket and scaffolding, and greatly improve the safety and efficiency.
Advantages & Features：
1.Diesel small telescopic boom lift the maximum working height of the whole machine covers 16m-58m
2.High-strength boom lift mechanism
3.Energy efficient electric drive system
4.Perfect active/passive safety protection system.
5. Suitable for multiple people working at the same time
6. Stable structure, no noise, zero emission and low failure rate.
7. Reliable operation, safety and efficiency, long-lasting life, convenient maintenance
8.diesel small telescopic boom lift is widely used in factories, warehouses, airports, stations and other terrain.
Hot Tags: diesel small telescopic boom lift, China diesel small telescopic boom lift manufacturers, suppliers, factory, telescopic boom lift service manual, telescopic boom lift insurance, telescopic boom lift financing, telescopic boom lift lease term, telescopic boom lift maintenance contract, telescopic boom lift departure angle instructions
Product Parameters：
| Diesel Telescopic Boom Lift Models and Parameters | ||||||
| Model | S28D | S32D | S38D | S42D | S46D | S56D |
| Max Working Height | 30m | 34m | 40.4m | 44m | 48m | 58m |
| Max Platform Height | 28m | 32m | 38.4m | 42m | 46m | 56m |
| Max Operating Radius | 20.6m | 21.4m | 24m | 24m | 23.6m | 26m |
| Platform Dimensions (L*W) | 2.44*0.91m | 2.44*0.91m | 2.44*0.91m | 2.44*0.91m | 2.44*0.91m | 2.44*0.91m |
| Machine Weight | 16800kg | 19250 kg | 22900 kg | 24600kg | 23110 kg | 27500kg |
| Load Capacity | 300kg/480kg | 300kg/480kg | 300kg/480kg | 300kg/480kg | 300kg/480kg | 300kg/480kg |
| Power | 53kw/2200rpm | 54kw/2400rpm | 54kw/2400rpm | 53kw/2200rpm | 54kw/2200rpm | 74kw/2400rpm |
| Fuel Tank Volume | 151L | 151L | 151L | 151L | 151L | 200L |
| Control Voltage | 12V | 12V | 12V | 12V | 12V | 24V |
| Electric Telescopic Boom Lift Models and Parameters | ||||
| Model | S18 | S20 | S24Li | S26Li |
| Max Working Height | 20.5m | 21.6m | 26.2m | 28.8m |
| Max Platform Height | 18.5m | 19.6m | 24.2m | 26.8m |
| Max Working Radius | 13.2m | 14.5m | 20m | 22m |
| Platform Dimension (L*W) | 1.8*0.75m | 1.8*0.75m | 2.4*0.9m | 2.4*0.9m |
| Machine Weight | 8520kg | 9100kg | 15100kg | 16600kg |
| Load Capacity | 300kg | 300kg | 300kg/450kg | 300kg/450kg |
| Driving Speed (Stowed) | 4.8km/h | 4.8km/h | 5.5km/h | 5.5km/h |
| Battery Power | 48V/420Ah | 48V/420Ah | 80V/500Ah | 80V/500Ah |
| Pump Motor Power | 12kw | 12kw | 30kw | 7kw |
| Driving Motor Power | 3.3kw | 3.3kw | 5.2kw | 5.2kw |
| Control Voltage | 12V | 12V | 12V | 12V |
| LFP Battery | Optional | Optional | Standard | Standard |
| Power Plus Generator | Optional | Optional | Optional | Optional |
| Insulated Platform | Optional | Optional | Optional | Optional |
